Home > All Collections > Others > Power Splitter > 1000～40000 MHz 2.92mm Female Power Divider 50 Ohm Wide-Band Signal Splitter
  • 1000～40000 MHz 2.92mm Female Power Divider 50 Ohm Wide-Band Signal Splitter
  • 1000～40000 MHz 2.92mm Female Power Divider 50 Ohm Wide-Band Signal Splitter

1000～40000 MHz 2.92mm Female Power Divider 50 Ohm Wide-Band Signal Splitter

No.MDC-1/40-10K
CONTACT US
  • 1000～40000 MHz 2.92mm Female Power Divider 50 Ohm Wide-Band Signal Splitter
Description

Specifications

Frequency Range ：1000～40000 MHz

Insertion Loss≤2.5 dB

VSWR Primary：Type. 1.5 / Max. 1.7

VSWR Secondary：Type. 1.5 / Max. 1.7

Directivity：Min. 10 dB

Frequency Sensitivity：±1.0dB

Nominal Coupling：10±1.2dB

Impedance：50 Ohms

Input/Output Connectors：2.92mm-Female

Power Rating：30W

Operation Temperature：-45℃ ~ +85℃

Surface Finishing：Black paint
