  • 1000～50000 MHz 2.4mm Female Power Divider 50 Ohm Wide-Band Signal Splitter
  • 1000～50000 MHz 2.4mm Female Power Divider 50 Ohm Wide-Band Signal Splitter

1000～50000 MHz 2.4mm Female Power Divider 50 Ohm Wide-Band Signal Splitter

No.MDC-1/50-10Q
CONTACT US
  • 1000～50000 MHz 2.4mm Female Power Divider 50 Ohm Wide-Band Signal Splitter
Description

Specifications

Frequency Range：1000～50000 MHz

Insertion Loss≤2.8 dB（Excluding Coupling）

VSWR Primary≤ 1.70

VSWR Secondary ≤ 1.70

Directivity：Min. 10dB

Frequency Sensitivity：±1.5dB

Nominal Coupling：10 ± 2.0dB

Impedance：50 Ohms

Input/Output Connectors：2.4mm-Female

Power Rating：20W

Operation Temperature：-45℃ ~ +85℃

Surface Finishing：Black paint
