Specifications
Frequency Range :470～990 MHz
Insertion Loss≤0.6 dB（Excluding theoretical loss:6.0 dB）
Input Port VSWR:Typ.1.16 / Max.1.20
Output Port VSWR:Typ.1.12 / Max.1.25
Isolation ≥20dB
Amplitude Balance:±0.2dB
Phase Balance:±2°
Impedance:50 Ohms
Input/Output Connectors:BNC-Female
Power Rating:Combiner:3W（1.5W）
Operation Temperature:-35℃ ~ +75℃
Surface Finishing:Sandblasting natural color conductive oxide
Outline Dimensions:176*150*20（mm）
