Specifications
Frequency Range：500～8000 MHz
Insertion Loss≤ 2.0 dB
VSWR Primary：Typ.1.18 / Max.1.50
VSWR Secondary：Typ.1.18 / Max.1.50
Directivity：Min. 10dB
Frequency Sensitivity：Type. ±0.9dB / Max. ±1.0dB
Nominal Coupling：6 ±1.5dB
Impedance：50 Ohms
Input/Output Connectors：SMA-Female
Power Rating：Average.30W
Operation Temperature：-45℃ ~ +85℃
Surface Finishing：Sandblasting natural color conductive oxide
