Home > All Collections > 2.4GHz 9dBi Omni WIFI Outdoor Antenna N female
  • 2.4GHz 9dBi Omni WIFI Outdoor Antenna N female
  • 2.4GHz 9dBi Omni WIFI Outdoor Antenna N female

2.4GHz 9dBi Omni WIFI Outdoor Antenna N female

No.WA2-256-N01SJ4-090
Type：WIFI AntennaCenter Frequency：2.4GHzConnector Series：NConnector Gender：Jack StraightImpedance：50Nominal Gain：9dbiV.S.W.R：≤1.5Antenna Size：60cm
CONTACT US
  • 2.4GHz 9dBi Omni WIFI Outdoor Antenna N female
Description

Electrical specifications
Frequency Range-MHz:2400-2483
VSWR :≤1.5
Input Impedance-Ω :50
Gain-dBi :9
Polarization: Vertical
F/B ratio-dB
Horizontal Beamwidth -°: 360
Vertical Beamwidth -°:22
Maximum Power -W:500
Bandwidth-MHz:83
Connector:N-female
Mechanical Specifications
High:60cm
Weight: 400g
Mounting Mast Diameter-mm Φ50-100
