Specification:
Frequency Range（MHz）: 433+/-15
Bandwidth（MHz）: 30
VSWR ≤1.5
Gain（dBi）: 3
Max Input power（W）:50
Input Impedance（Ω）: 50
Polarization Type :Vertical
Antenna High（mm）: 170
Cable Length﹙mm﹚: 3000
Cable Type : RG174
Connector Type :SMA Plug connector
Mounting: Magnetic
Radiation :Omni-direction
Max Diameter :30mm
Min Diameter :1.5mm
Max wind speed :200km/h
If you need this antenna with SMB/SMC/BNC/FME/TNC/MCX /MMCX connector or other, please contact us.
