Home > All Collections > 4G LTE 3dBi Omni-directional SMA Male Antenna for 4G LTE Wireless Router Module Remote IP Camera Vehicle Home Mobile Cell Phone Booster System
  • 4G LTE 3dBi Omni-directional SMA Male Antenna for 4G LTE Wireless Router Module Remote IP Camera Vehicle Home Mobile Cell Phone Booster System
  • 4G LTE 3dBi Omni-directional SMA Male Antenna for 4G LTE Wireless Router Module Remote IP Camera Vehicle Home Mobile Cell Phone Booster System
  • 4G LTE 3dBi Omni-directional SMA Male Antenna for 4G LTE Wireless Router Module Remote IP Camera Vehicle Home Mobile Cell Phone Booster System
  • 4G LTE 3dBi Omni-directional SMA Male Antenna for 4G LTE Wireless Router Module Remote IP Camera Vehicle Home Mobile Cell Phone Booster System
  • 4G LTE 3dBi Omni-directional SMA Male Antenna for 4G LTE Wireless Router Module Remote IP Camera Vehicle Home Mobile Cell Phone Booster System
  • 4G LTE 3dBi Omni-directional SMA Male Antenna for 4G LTE Wireless Router Module Remote IP Camera Vehicle Home Mobile Cell Phone Booster System
  • 4G LTE 3dBi Omni-directional SMA Male Antenna for 4G LTE Wireless Router Module Remote IP Camera Vehicle Home Mobile Cell Phone Booster System
  • 4G LTE 3dBi Omni-directional SMA Male Antenna for 4G LTE Wireless Router Module Remote IP Camera Vehicle Home Mobile Cell Phone Booster System
  • 4G LTE 3dBi Omni-directional SMA Male Antenna for 4G LTE Wireless Router Module Remote IP Camera Vehicle Home Mobile Cell Phone Booster System
  • 4G LTE 3dBi Omni-directional SMA Male Antenna for 4G LTE Wireless Router Module Remote IP Camera Vehicle Home Mobile Cell Phone Booster System

4G LTE 3dBi Omni-directional SMA Male Antenna for 4G LTE Wireless Router Module Remote IP Camera Vehicle Home Mobile Cell Phone Booster System

No.4A2-0159-S01SP-030
Antenna Type：Rubber DuckNetwork：4G/LTE AntennaFrequency：700-2600MhzConnector Series：SMAConnector Polarity：StandardConnector Gender：PlugGain：3dBiRadiation：OmnidirectionalV.S.W.R：≤1.5Weight：28g
CONTACT US
  • 4G LTE 3dBi Omni-directional SMA Male Antenna for 4G LTE Wireless Router Module Remote IP Camera Vehicle Home Mobile Cell Phone Booster System
  • 4G LTE 3dBi Omni-directional SMA Male Antenna for 4G LTE Wireless Router Module Remote IP Camera Vehicle Home Mobile Cell Phone Booster System
  • 4G LTE 3dBi Omni-directional SMA Male Antenna for 4G LTE Wireless Router Module Remote IP Camera Vehicle Home Mobile Cell Phone Booster System
  • 4G LTE 3dBi Omni-directional SMA Male Antenna for 4G LTE Wireless Router Module Remote IP Camera Vehicle Home Mobile Cell Phone Booster System
  • 4G LTE 3dBi Omni-directional SMA Male Antenna for 4G LTE Wireless Router Module Remote IP Camera Vehicle Home Mobile Cell Phone Booster System
Description

4G LTE 3dBi Omni-directional SMA Male Antenna for 4G LTE Wireless Router Module Remote IP Camera Vehicle Home Mobile Cell Phone Booster System


4G LTE Antenna Specification:

Frequency Range: 698~960/1710~2690MHz

Polarization: Linear

Gain: 3dBi typ.

V.S.W.R: ＜3.0

Impendance: 50Ω

Connector: SMA Male Connector

Weight: 28g


Environmental:

Operating Temperature: -40℃~+85℃

Relative Humidity: Up to 95%

Vibration: 10 to 55Hz with 1.5mm amplitude 2hours

Environmentally Friendly: ROHS Compliant
