This 5 dBi omnidirectional RFID antenna offers reliable tag reading performance in the 902-928 MHz frequency range. Its balanced beamwidth (Hor: 60° Ver: 60°) provides good coverage for applications that prioritize consistent reading within a designated area, such as warehouse management, door control systems, and industrial management systems. The compact and weatherproof design (IP65/IP67) makes it suitable for various indoor and outdoor environments.
• Efficient Reading in Your Coverage Zone
With a gain of 5 dBi, this antenna transmits a dependable signal, enabling consistent tag reads within its coverage area. This is ideal for applications where tags are located within a defined zone, ensuring efficient workflow in warehouses, access control points, and other controlled environments.
• Balanced Beamwidth for Consistent Coverage
The antenna's balanced beamwidth of 60 degrees horizontally and vertically provides comprehensive coverage in all directions. This eliminates the need for precise antenna positioning and ensures consistent tag reading performance throughout the designated area.
• Circular Polarization for Diverse Tag Orientations
The antenna utilizes circular polarization, which effectively reads tags regardless of their orientation. This eliminates the need for specific tag placement, making it suitable for environments where tag orientation might vary.
• Rugged Construction for Reliable Operation
Built to endure various conditions, the antenna boasts an IP65/IP67 waterproof rating. This protects it from dust, rain, and harsh weather elements, guaranteeing reliable operation in indoor and outdoor environments.
| Frequency | 902-928 MHz (866±5 MHz) |
| Gain | 5 dBi |
| Beam Width | Hor: 60° Ver: 60° |
| Polarization | Circular |
| VSWR | ≤ 1.3 |
| Impedance | 50Ω |
| Lightning Protection | DC Ground |
| Connector | N-Female/Male, TNC |
| Dimension | 130 x 130 x 18 mm |
| Radome Material | ABS |
| Radome Color | White |
| Operating Temperature | -20°C to 60°C |
| Waterproof Rate | IP65/IP67 |
