Tailored Solutions: Customizable designs to meet specific requirements.
Superior Performance: Excellent isolation and high efficiency for reliable communication.
Broad Frequency Range: Supports both 5G and Wi-Fi frequencies.
Versatile Applications: Ideal for a variety of vehicles, including cars, caravans, engineering vehicles, and agricultural equipment
1. Can customize products
2. Customized design
3. Good isolation, high efficiency.
• High performance amplifiers & filters
This combination antenna has built-in amplifiers and filters to enhance the received signal and reduce noise interferences.
• Anti-interference
To ensure stable operation in complex environments, this antenna is specially designed to reduce interference from other wireless devices.
• Multi-band Coverage
Antennas usually support 5G and Wi-Fi network connection communication.
• Good Isolation
The 5G+Wi-Fi combination antenna has good isolation between antennas, which ensures that the signals between antennas do not leak and do not interfere with each other, improves the overall performance of the antenna, and reduces the influence of the antenna on the measurement error during communication interaction.
| Function | 5G Antenna Part (Main) | 5G Antenna Part (Div) | Wi-Fi Antenna Part |
| Frequency Range | 700~960/1710~2690/3300~5000MHz | 700~960/1710~2690/3300~5000MHz | 2400~2500/5150~5850MHz |
| V.S.W.R | ＜3/＜2.5/<2.5 | ＜3/＜2.5/<2.5 | ＜2/＜2 |
| lmpedance | 50±3Ω | 50±3Ω | 50±3Ω |
| Polarization | Linear | Linear | Linear |
| gain | ≥0dBi | ≥0dBi | ≥0dBi |
| Isolation | ≥10dB | ≥10dB | ≥10dB |
| Environmental Requirements | |
| (1) Operating temperature | -40℃ ~ +85℃ |
| (2) Storage temperature | -40℃ ~ +90℃ |
| (3) Protection grade | IP52 (after vehicle assembly) |
