Wi-Fi fiberglass antennas also play an important role in indoor environments. It can be installed in offices, shopping malls, hotels and other places, providing people with convenient and efficient wireless network services. Whether it's business meetings, shopping experiences, or leisure entertainment, Wi-Fi fiberglass antennas can ensure smooth network connectivity and improve people's quality of life.
• Good signal reception capability
It can effectively receive and transmit Wi-Fi signals, providing good network coverage and connection stability.
• Strong weather resistance
Able to adapt to various outdoor environmental conditions, such as temperature changes, humidity, wind and rain, and has a long service life.
• Good directionality
It can strengthen the signal in a specific direction, which helps to improve the directionality and gain of the signal.
• Beautiful appearance
It can be designed into different shapes and appearances according to needs, and has good adaptability to the installation environment.
| Frequency Range | 5150-5850MHz |
| Impedance | 50Ω |
| VSWR | ≤2.0 |
| Gain | < 6.0dBi |
| Max efficiency | <73% |
| Polarization | Vertical |
| Radiation | Omni |
| Connector | N-J |
| Length | 230±3mm |
Installation suggestion
we recommend that you install the antenna in an open place, and keep it as vertical as possible. Install the antenna in the highest place outdoors would help you to get a better signal. However, if used indoors, it is recommend to place them near a window.
 |
 |
| Optional connector and accessories are availiable. Please share your requirement with us to get the best offer. | The fiberglass antenna are speciall suitable for outdoor installation. It can work well with your Helium miner hotsport, internet gateway and any long range communication systems and euiqpments. |
VLG glass antenna series
| Model | 2dB-2.4 | 4dB-2.4 | 6dB-2.4 | 4dB-5.8 | 6dB-5.8 | 6dB-2.4/5.8 |
| Frequency Range | 2400-2500MHz | 2400-2500MHz | 2400-2500MHz | 5150-5850MHz | 5150-5850MHz | 2400-2500/5150-5850MHz |
| Gain | 2dBi | 4±1dBi | 6.0±1 dBi | 4±1dBi | 5.0±1 dBi | 4.0dBi /6.0dBi |
| VSWR | ≤1.5 | ≤2.0 | ≤2.0 | ≤2.0 | ≤2.0 | ≤3.0 |
| ovality(dB) | ≤±2 | ≤±2 | ≤±2 | ≤±2 | ≤±2 | ≤±2 |
| Impedance | 50Ω | 50Ω | 50Ω | 50Ω | 50Ω | 50Ω |
| Max input power | 50W | 50W | 50W | 50W | 50W | 50W |
| Dimensions（mm） | ɸ20*215 | ɸ20*220 | ɸ20*350 | ɸ20*185 | ɸ20*185 | ɸ20*270 |
| Connector type | N-K/J | N-K/J | N-K/J | N-K/J | N-K/J | N-K/J |
| Radome material | Fiberglass | Fiberglass | Fiberglass | Fiberglass | Fiberglass | Fiberglass |
