Model:3A3-880-N01SJ-030-16
Frequency Range(MHz): 806-960MHz/1710-2500MHz
Bandwidth:100 MHz
Gain: 3 dBi
F/B ratio:15 dB
VSWR:≤1.5
Max power:100 W
Nominal Impedance:50Ω
Connector: N Jack default
SMA/SSMB/CRC9/TS9/MCX/MMCX/FME/BNC/TNC/SMB/MC-Card/MS-147..and so on.,please give us notes if the other connector is chosen !
Dimension:Φ180×90 mm
800MHz+900MHz+1800MHz+1900MHz+3G+2400MHz WLAN
GSM 850/900: 824 - 960Mhz
GSM 1800/1900:1710 - 2500Mhz
UMTS: 1900 - 2170 MHz
CDMA 800/1900
800MHz+900MHz+1800MHz+1900MHz+3G+2400MHz WLAN Ceiling
