Boosts antenna strenght up to 13 dB
Frequency Range(MHz)850-960/1710-2170
GSM/GPRS/EDGE 850/900/1800/1900MHz
HSUPA/HSDPA/UMTS 2100MHz/900MHz
CDMA 1900 MHz
VSWR ≤1.5
Enhance and maintain excellent signal quality
Usable indoor or outdoors
Quick, simple installation, no software required
Mount:Maganic base
Antenna Connector: CRC9 male straight default
Optional conector: SMA/SSMB/SMB/N/TS9/CRC9/MS147/MCX/MMCX/FME/BNC/TNC/MC-Card..and so on.,please give us notes if the connector is chosen!
Antenna length:17cm
Cable length:46cm, RG174
Antenna Weight:48g
CRC9 connector/ adapter for HUAWEI USB Modems
SSMB connector for huawei E800 E870
MC-LUCENT connector for Option Wireless
MCX male for Ericcson W30/W35 data router
MMCX male for Ericsson MC95/MC99/RLMC352
SMA male for Ericsson W21
