Specifications:
Amplifier
Frequency Range：DAB:174~240MHz， AM:520~1710KHz ， FM:87.8~108MHz
Working Voltage: 9.0v~16.0v
Working Current: 30mA~60mA
Gain:DAB:18±2dB
AM/FM:-2±2dB
Impendance: 50Ω
V.S.W.R:＜3.0:1
Mechanical
Cable：RG174
Connector：Car Antenna Plug&Socket SMB
Fuse：500mA
PCB：FR4
Plastic Housing：ABS
Environmental
Store Temperature ：-35℃~+90℃
Operating Temperature ：-40℃~+85℃
Relative Humidity：Up to 75%
Vibration：10 to 55Hz with 1.5mm amplitude 2hours
Environmentally Friendly：ROHS Compliant
Advantages
Converts existing FM/AM aerials so that they can be used with DAB radios.
DAB/DAB+/DMB-A compatible
Uses existing FM/AM aerial.
Retains original appearance of vehicle
Small, neat and hidden.
Listing Suitable for the following DAB radios
Alpine DAB except Ezi-DAB
Beat DAB except 400 & 485
Blaupunkt DAB
Caliber Caliber DAB except PMT-700D
C-KO DAB
Clarion Clarion DAB except DAB302E
Clarity CCE203-DAB
Grundig DAB
JVC DAB
Kenwood DAB
Kinetic All in-Car DAB
pioneer All in-car DAB except GEX-P900DAB
philips CEM.....series
pure Highway H240Di H260D
Sonichi SB50-DAB
Sony DAB
