Electrical Specifications:
Frequency Range:890-960/1710-1880MHz
Gain: 2dBi
VSWR: ≤2.0
Polarization: Vertical
Impedance: 50Ω
Maximum Input Power: 50W
Cable type: RG174
Cable length: 30CM
Connector :SMA Plug defalut
Option :SMA/SSMB/MCX/FME/BNC/TNC/and so on.,please give us notes if the connector is chosen !
Operating Temperature:-40℃ to+80℃
Weight: 71g
Applications:
Mobile Antenna is designed for the spread spectrum communication system.
This antenna has good VSWR.
The light structure and small dimension makes it easy to install.
The performance of it is stable.
It also has excellent shockproof and anti-aging performance
