PHYSICAL PROPERTIES
| Material | Diameter(mm) | |
| 1．Inner conductor | Copper Clad Steel or Bare Copper | 0.81 |
| 2．Insulation | Foam Polyethy lene | 3.66 |
| 3．Outer conductor | Single-sided Aluminum Tape and Tinned Copper Wire or Aluminum Magnesium Alloy Braiding | 4.35 |
| 4．Jacket | PVC | 6.10 |
ELECTRICAL PROPERTIES
| Nom. Rated Capacitance (pF/m) | 53 |
Nom. Characteristic Impedance(ohm) | 75 |
| Nom. Velocity of Propagation(％) | 82 |
| Min. Bend Radius(Install)(mm) | 61 |
| VSWR | 1-1000MHz≤1.15 1-2000MHz≤1.20 |
| Max. Operating Frequency(MHz) | 1-2000MHz |
| Operating Temperature Rating(℃) | -20～+70 |
Attenuation at typical frequencies
| MHz ≤db/100m | MHz ≤db/100m |
| 1 1.09 | 200 17.2 |
| 20 4.92 | 400 23.0 |
| 150 13.8 | 900 35.6 |
