Product name VLG-OS1835-U9
Antenna size 18x35mm
Chip NXP UCODE 8 /NXP UCODE 9
Frequency 860MHz-960MHz
Reading distance 8m
EPC area 128Bits/96Bits
TID Contains 96Bits
Service life 100,000 erase/data retention for 50 years
Application Scenarios Retail/Medical drugs
• Uhf
The frequency 860MHz to 960MHz band, providing a longer reading distance and a higher data transfer rate.
• Long reading distance
Thanks to advanced chip technology and antenna design, the reading distance of the RFID antenna can reach 8 meters, which greatly facilitates the tracking and management of goods in large retail stores or warehouses.
• Large data storage
the antenna has a built-in EPC area and TID area, with 96Bits and 96Bits of storage space, which can store rich product information to meet various application needs.
• Durability
The antenna supports up to 100,000 erase operations and retains data for up to 50 years, ensuring stability and reliability for long, high-frequency use.
| Model | OS31280 | OS331468 |
| Delivery Format | Dry Inlay | Label |
| EPC Memory | 96Bits | 96Bits |
| User Memory | 0Bits | 0Bits |
| Die-cut Dimension | - | 46*23mm |
| Inlay Substrate | 50um PET | 50um PET |
| Standard Pitch | 25.4mm | 25.4mm |
| Web Width | 70mm | 56mm |
| Core Size | 76.2mm/3inch | 76.2mm/3inch |
| Quantity / Reel | 10000±300Pcs/Reel | 2500±2Pcs/Reel |
| Operating Temperature | -20℃ to +50℃ （20% to 80%RH） | |
| Remarks | Wet inlay and Label are regular size. Other size can be customize | |
| Frequency | 860MHz-960MHz | |
| Chip NXP UCODE9 | NXP UCODE9 | |
| International Standard | ISO/IEC 18000-63 Type C | |
