Frequency AM: 535KHz~1605KHz, FM:88MHz～108MHz
Output VSWR: ＜3@98MHz
Output Impedance: 75Ω
Polarization: Linear polarization
Dimensions: 190mm(L)
Application: Fits most vehicle truck car marine boat stereo receivers media head units CD radios, like Sony, Pioneer, Alpine,etc
• Good material, good quality
The antenna adopted with premium metal and wrapped by flexible rubber,ensure the resistance and durability.
• Flexible Mast
The antenna is made of durable flexible rubber, which will always spring back into shape when you bent it. User won't need to remove the antenna when going through the car wash.
• Installation Fast
Antenna installation is very convenient, less than a minute you can install without any external tools.All you need is screw off the old antenna and screw on this.
| Function | AM/FM |
| Frequency | AM :535KHz~1605KHz, FM:88MHz～108MHz |
| Output VSWR | ＜3@98MHz |
| Impedance | 75Ω |
| Polarization | Linear polarization |
| Connector | JASO |
| Antenna Length | 190mm(L) |
| Environmental Requirements | |
| Operating temperature | -40℃ ~ +85℃ |
| Protection grade | IP65 |
| Connector pulling force | >98N |
