Frequency AM: 535KHz~1605KHz, FM:88MHz～108MHz
Output VSWR: ＜3@98MHz
Output Impedance: 75Ω
Polarization: Linear polarization
Dimensions: 175mm(L)×Ø11mm
Cable: 150mm (1.5C-2V )
Connector: JASO
Application: Fits most vehicle, truck, car, marine boat stereo receivers media head units CD radios, like Sony, Pioneer, Alpine,etc
• Flexible Mast
19cm long, external part making of durable rubber, the antenna is flexible and weatherproof, you can go through the car wash without removing it.
• Highly Conductive Copper Coil
The internal part is made of high quality copper coil, which provides better signal reception and allows you pick up more radio stations
• Mounting Method
Hole drilling on car roof or fender.
| Function | AM/FM |
| Frequency | AM :535KHz~1605KHz, FM:88MHz～108MHz |
| Output VSWR | ＜3@98MHz |
| Impedance | 75Ω |
| Polarization | Linear polarization |
| Connector | JASO |
| Dimensions | 175mm(L)×Ø11mm |
| Environmental Requirements | |
| Operating temperature | -40℃ ~ +85℃ |
| Protection grade | IP65 |
| Connector pulling force | >98N |
